ATxTel ShieldProAtten
Programmable Variable Attenuator
ShieldProAtten is ATxTel’s new in a series of programmable RF attenuators. A completely custom-machined aluminum enclosure offers excellent RF isolation, making it suitable for Wi-Fi, cellular, and any RF-sensitive testing applications. ShieldProAtten provides both USB and Power over Ethernet (PoE) interfaces for simple testbed integration and network control.
Key features
- Independent-controlled RF channels programmable attenuator
- 95dB of attenuation range in 0.1dB step size
- Frequency range from 50MHz to 8000 MHz
- Custom machined aluminum RF isolated enclosure
- USB or Ethernet control (support PoE)
- Intuitive web graphical interface
- Compact and stackable size
Specifications
|
Parameter |
Specification |
|||
|
Frequency Range |
50MHz - 8GHz |
|||
|
Variable Attenuation Range |
0 to 95dB |
|||
|
Attenuation Step Size |
0.1dB |
|||
|
Insertion Loss |
< 2GHz |
2-4GHz |
4-6GHz |
6-8GHz |
|
7dB max |
9dB max |
11dB max |
14dB max |
|
|
RF Input Power |
29dBm max |
|||
|
0.1dB Input Compression Point |
>33dBm |
|||
|
Input 3rd Order Intercept |
56dBm |
|||
|
Adjacent Channel Isolation |
>100dB |
|||
|
Return Loss |
0dB Attenuation |
>10dB Attenuation |
||
|
< -10dB |
< -15dB |
|||
|
Absolute Attenuation Accuracy |
+/- 0.7dB |
|||
